Designed for clean-room environments, these Class 100 and Class 10M-100M panels are sag-resistant and adhere to ISO standards.
CLEAN ROOM® ClimaPlus™ acoustical suspended ceiling panels are perfect for ISO 5, 100-rated to 10M-100M- rated clean rooms, computer and control rooms, kitchens/food prep areas (ISO 5 or Class 100 only) and sterile rooms.
They are designed with FIRECODE® for use in fire-rated assemblies and are available with High Recycled Content (HRC).
CLEAN ROOM ClimaPlus acoustical ceiling panels are not only designed to meet Federal Standard 209E, "Clean Room and Work Station Requirements Controlled Environments," but their design also ensures they are sag-resistant and easy to clean. This makes them the perfect choice for Clean Room environments.
Clean Room™ ClimaPlus™ Class 100 and Class 10M–100M panels have an embossed, vinyl-laminated face with sealed back and edges for use in ISO 5 and Class 100 or 10M–100M clean rooms
USDA Certified Bio-based Product
FireCode® product designed to meet life-safety codes
ClimaPlus 30-year lifetime system warranty against visible sag
Available with High Recycled Content (HRC)
Low-emitting product
Physical Properties
Type: Acoustical Ceiling Panels, Acoustical Suspended Ceiling Panels
For use in a fire rated system
Material: Mineral Fiber
Humidity Resistant
Sag Resistant
Texture: Fine, Smooth
Colour: White
Edge Profile: Square Edge
Panel Size: 600x600mm; 600x1200mm
Panel Thickness: 15 mm
CAC: 35-39
Light Reflectance: .79
NRC: 0.55 to 0.60 (Class 10M-100M)
ISO 5 Cleanroom
Sustainability
Up to 50.5 % Recycled
Applications
Kitchens/Food Prep Areas, Laboratories/Operating Rooms/Imaging Rooms, Nurseries/Birthing Rooms, Patient Rooms, Restrooms/Utility Rooms/Loading Docks[/vc_column_text][/vc_column_inner][vc_column_inner width="1/2"][vc_gallery type="flexslider_slide" interval="3" images="7890,7891,7892" img_size="540x390" el_class="productzoom-icon"][/vc_column_inner][/vc_row_inner][vc_row_inner content_placement="middle" disable_element="yes" el_class="properties-section py-100"][vc_column_inner width="1/2"][vc_single_image image="6112" img_size="full"][/vc_column_inner][vc_column_inner width="1/2"][vc_column_text el_class="image-width-text-content"]All our aluminium partition suites carry the Declare label.
Final Assembly: New Zealand. Life Expectancy: 50+ years. End of of Life Options: 100% Reusable/Recyclable.
If you would like design assistance please email our specification team on specsupport@potters.co.nz[/vc_column_text][/vc_column_inner][/vc_row_inner][vc_row_inner disable_element="yes" el_id="profile_options" el_class="releated_products"][vc_column_inner][vc_column_text el_class="bg-section-grey py-100"]
